Description
This is a simple replacement wall support clip for wire shelving. It is made to hold the rear wire of a shelf or rack against the wall, similar to the small white plastic clips commonly used with wire closet shelves.

Useful when the original clip is broken, missing, or too weak. The part can be printed quickly and replaced without buying a full hardware kit.

Suggested use:
Mount the clip to the wall with a screw, then place the rear wire of the shelf into the retaining slot. Make sure the shelf is properly supported with brackets or side supports. This clip is mainly intended as a retaining/support clip, not as the only load-bearing support.

Print settings
Material: PETG recommended, PLA acceptable for light duty
Layer height: 0.16 mm or 0.20 mm
Infill: 40% to 60%
Walls: 4
Top/bottom layers: 5
Supports: Not required, depending on orientation
Orientation: Print flat on the back face for best strength
Nozzle: 0.4 mm

Recommended material note
PETG is better than PLA if the part will see stress, humidity, or temperature changes. PLA is fine for testing or light indoor use.
