Sort beads quickly and consistently with this compact interchangeable bead sieve system. Designed for hobbyists, crafters, and makers, this sieve includes 8 removable 4 mm thick grates with tight tolerances ranging from 2.5 mm to 9.5 mm, making it ideal for separating beads by size. Also ideal for culling seed beads as well!

The storage box keeps all sieves organised, while the removable base makes it easy to clear trapped beads or debris during use. If smaller beads become lodged in the sieve openings, a knitting needle or crochet hook works perfectly for clearing them.

This design is also easy to upscale for sorting other small items such as machine screws, nuts, bolts, interconnecting bricks, and similar components.

Dimensions:
Length: 95 mm
Width: 95 mm
Height: 65 mm
Grates are 3.5mm thick

Features:
• 8 interchangeable sorting sieves
• Tight tolerance sizing from 2.5 mm to 9.5 mm
• Integrated storage box for grates
• Removable base for easy cleaning
• No supports required
• Easy to scale for other sorting applications

Recommended Print Settings:
• Material: PLA (matte PLA recommended for best finish)
• Nozzle Size: 0.4 mm
• Layer Height: 0.20 mm
• Initial Layer Height: 0.20 mm
• Infill: 15% gyroid

Printing Notes:
Due to the tight grate tolerances, printer calibration is recommended for the best sorting accuracy.

What’s Included:

• .STL files
• .3MF files with pre-set print settings
