Compact radial generator of 140mm of diameter that can produce up to 15V RMS (29.2V Peak). Rotor is around 100mm with 1mm radial gap.

The generator consists of 3 sub-assemblies: Stator, Rotor and Planetary Gearbox. Kv constant is around 35 RPM/V. See the figure in the pictures. The radial generator features a planetary gearbox with 3:1 ratio (rotor spins 3 times faster than input shaft).

Videos showing the generator in actions : [https://youtube.com/shorts/lqbEw0c9WKA?feature=share](https://youtube.com/shorts/lqbEw0c9WKA?feature=share)

Material needed for assembly :

Stator :

• 2 guide bearing 5972K281
• 12 brass insert M3 5mm
• 12 M3 screws
• 12 oz enamelled copper wire 24 AWG

Rotor:

• 6 brass insert M3 5mm
• 6 M3 screws
• 18 magnets 10x60x5 mm

Planetary gearbox:

• 3 brass insert M3 5mm
• 3 M3 screws
