Modular Removable Snap Rivet - Fully Parametric

This is a fully parametric, 3D-printable removable snap rivet system designed for modular builds, panels, enclosures, organizers, trays, and custom fixtures. Instead of using a permanent rivet, this design uses a reusable split-body rivet with interchangeable locking pins and optional spacer collars, so it can be installed, removed, and reused without damaging the part.

The model is built as a customizable system for different hole sizes, grip thicknesses, and locking strength. It is ideal for prototype assemblies, lightweight panels, modular boxes, printed accessories, and other projects where you want a clean fastener look without using third-party hardware.

Features

• Fully parametric design
• Reusable removable rivet system
• Split-body snap rivet with center locking pin
• Interchangeable light and strong lock pin styles
• Optional spacer collars for different panel stack thicknesses
• Adjustable hole diameter, grip range, clearance, and head style
• Separate part export modes and assembly preview
• Designed for easy customization in MakerWorld

Great for

• Modular enclosures
• Lightweight panel fastening
• 3D printed boxes and trays
• Prototype builds
• Replaceable printed hardware
• Small removable plastic fasteners

Print notes

For very small sizes like the 2 mm version, a 0.2 mm nozzle is strongly recommended. PETG works best for durability and repeat use. PLA can work for test fitting, but PETG is the better choice for functional parts.

Recommended settings

• 0.2 mm nozzle for micro sizes
• 0.08 to 0.12 mm layer height for tiny parts
• PETG recommended
• Slow outer walls for best fit
• Print body upright for best leg flex
• Print locking pin upright for best detail

Important note

The 2 mm version is extremely small and meant for fine-detail printing. For easier printing and stronger real-world use, scaling this design to 3 mm, 4 mm, or 5 mm hole sizes is recommended.

Why I made this

I wanted a printable rivet that looks clean, installs easily, and can actually be removed without destroying the part. Most plastic push rivets are single-use or not well suited for FDM printing, so this design focuses on printability, modularity, and real reuse.
