Overview

This Fallout 4–inspired terminal case transforms your Raspberry Pi 4 into a retro-futuristic desktop or wall-mounted display. It integrates a 7" touchscreen, front-facing USB ports, and rear-mounted power and Ethernet connections for a clean, functional build. Ideal for dashboards, media terminals, or themed setups.

Features

• Fallout-style terminal aesthetic with functional layout
• Designed for Raspberry Pi 4 + official 7" touchscreen
• Front panel supports 2x USB 2.0 + 2x USB 3.0 extensions or any combination
• Rear panel supports Ethernet, USB-C power, and external power button
• Internal mounting frame for secure component placement
• Ventilation slots for passive cooling
• Multiple mounting options (desktop or hanging display)

Print Settings

• Material: PLA (tested with Bambu Gray, Sunlu Olive Green, Bambu Black)
• Layer Height: 0.2 mm (or better) recommended
• Supports: Minimal (only where required)
• Infill: 15–25%

Hardware / Assembly

Core Components:

• Raspberry Pi 4
• Raspberry Pi Official 7" Touchscreen

Fasteners:

• 24x M5x8 screws
• 10x M3x8 screws

Rear Panel Components:

• USB-C panel mount power extension (30cm)
• RJ45 Ethernet panel mount extension (30cm)
• Momentary push button (power)

Front Panel Components:

• 2x USB 2.0 panel mount extensions
• 2x USB 3.0 panel mount extensions

Internal:

• Heat shrink tubing (for wire management)

Assembly Summary:

1. Mount internal frames to front panel (8x M5x8)
2. Install Raspberry Pi and connect touchscreen ribbon + power leads
3. Mount front USB extensions using M3x8 screws and connect to Pi
4. Attach bottom to shell (4x M5x8)
5. Attach front face to shell (4x M5x8)
6. Install rear components (Ethernet, USB-C, power button)
7. Wire power button to GPIO (recommended: GPIO 3 pin 5 + GND pin 14)
8. Connect Ethernet and USB power to Pi
9. Secure back plate (4x M5x8)

Compatibility

• Raspberry Pi 4 Model B
• Raspberry Pi Official 7" Touchscreen
• Standard panel-mount USB, Ethernet, and USB-C extensions (30cm recommended)
