🔧 Vileda Mop Joint Repair Part (Pivot Hinge Replacement)

+Version for no support

This is a functional replacement joint designed to restore the pivot mechanism of a Vileda-style flat mop. If your original hinge is cracked, loose, or completely broken — this part brings your mop back to life without buying a whole new unit.

🧩 What it does
- Replaces the main rotating joint between the mop head and handle mount
- Restores tilting / pivot motion for proper floor contact
- Designed for smooth rotation and durability

⚙️ Design features
- Reinforced pivot arm structure for improved strength vs original
- Integrated round mounting hole for secure axle/pin connection
- Side slot for handle locking mechanism
- Optimized geometry for FDM 3D printing (no supports needed in most orientations)
- Slightly thickened stress areas to prevent repeat failure

🛠️ Compatibility
- Fits many Vileda flat mop systems (verify dimensions before printing)
- Ideal for repairing worn or snapped plastic joints

💡 Why this part?
- Instead of replacing the whole mop, fix just the broken component:
- Save money 💰
- Save time on convenience store visits
- Reduce waste ♻️ less support

3D printing settings

🧪 Printing recommendations
Material: PETG / ABS / Nylon (PLA not recommended for long-term use)
Infill: 25%, wall generator Arachne
Walls: 3–5 perimeters 0.6-1mm wide line (3-5 mm thick wall)
Layer height: 0.2 mm (adaptive to speed 1.0)
Orientation: Print flat for maximum strength along the arm
