Reliable, error-free SolidWorks parametric Gridfinity baseplate. Unlike other broken models, this SolidWorks Gridfinity design uses robust constraints to easily change width and length variables without rebuild errors.

Build your custom organization system faster with a parametric Gridfinity baseplate that meets the exact 42mm specification. Includes integrated magnet holes for secure bin attachment and a clean feature tree for seamless customization in SolidWorks. Also attached is a .3MF with all variations from 1-5 width and length and another with all sizes up to 6x6 (with H2D setting). Regardless, you can easily just keep whichever sizes you like and use that for your prints.

Note that MakerWorld won't let me upload more than one SolidWorks part file per listing, so I had to split this design into three listings.

Here is the Gridfinity baseplate without magnet holders – just the simple frame for lower profile applications
Here are the parametric design and 3MF for Gridfinity bins

I'm happy to make adjustments if you need something. I'm also interested to learn how you use this design.
