This model allows you to easily customize:

• Length
• Width
• Height
• Text on lid

The lid features engraved, centered text that automatically resizes to fit within a safe area, maintaining at least 20 mm margin from all edges and a minimum text height of 5 mm.

🔧 Key Features

• ✅ No supports required – all parts print flat
• ✅ Stackable with lid attached
• ✅ Parametric sizing (3 main dimensions)
• ✅ Auto-scaling wall and bottom thickness
• ✅ Clean engraved text (no protrusions)
• ✅ Optimized tolerances for easy assembly

🔧 Assembly

After printing, lightly glue the 4 stacking connectors into the holes on the lid.

A small amount of super glue (CA) is enough.

🧩 Smart Stacking System

This design uses separate glue-on stacking connectors (“mushrooms”):

• Keeps the top surface clean (only shallow guide holes)
• Ensures accurate alignment between stacked boxes
• Provides stable stacking without tight locking

🖨️ Printing Tips

• Print all parts flat on the build plate
• No supports needed
• Recommended settings:
  • Layer height: 0.16–0.24 mm
  • 3–4 perimeters
  • 15–20% infill

After printing, simply glue the 4 connectors onto the lid.

📦 Parts Included

• 1× Box
• 1× Lid
• 4× Stacking connectors

💡 Notes

• Bottom thickness is automatically adjusted but never below 6 mm to support stacking features
• Lid overlap scales with size but is never below 10 mm
• All stacking elements keep fixed geometry for consistent fit across sizes
