📦 PARAMETRIC DRAWER ORGANIZER (UP TO 10 CUSTOM BOXES)

A fully customizable drawer storage system where you can design your own layout by adjusting up to 10 individual boxes, each with independent size and position control.

This model is designed for maximum flexibility, allowing you to perfectly fit any drawer shape without needing multiple separate files.

📐 UNITS (VERY IMPORTANT)

All values in this model are measured in:

👉 millimetres (mm)

Examples:

• 100 = 100mm = 10cm
• 50 = 50mm = 5cm

⚠️ Make sure your drawer measurements are also in mm.

🧠 HOW THIS MODEL WORKS

Instead of one fixed organizer, this model uses:

• Multiple independent boxes
• Each box can be resized
• Each box can be moved
• Boxes can be turned on or off
• Optional automatic grid layout

You are essentially building your own custom drawer system.

📏 STEP 1 — MEASURE YOUR DRAWER

Before changing anything in the model:

Measure:

• Internal length of drawer (left to right)
• Internal width of drawer (front to back)
• (Optional) height if you want a visual limit

Enter these values:

drawer_length drawer_width

💡 Tip:
Always measure inside edges, not outside.

📦 STEP 2 — UNDERSTAND THE BOX SYSTEM

You have up to 10 boxes available:

Each box includes:

• Enable switch (ON/OFF)
• Length (X size)
• Width (Y size)
• Height (Z size)
• Position X
• Position Y

Example:

box1_enable = 1 box1_length = 80 box1_width  = 60 box1_height = 50 box1_x = 0 box1_y = 0

🔘 STEP 3 — TURN BOXES ON OR OFF

Each box has an enable value:

1 = ON (box will appear) 0 = OFF (box is disabled)

👉 Only enable the boxes you actually want to use.

Example setup:

• Box 1 → ON
• Box 2 → ON
• Box 3–10 → OFF

📐 STEP 4 — SET BOX SIZES

For each active box, adjust:

Required values:

• box_length → left to right size
• box_width → front to back size
• box_height → vertical height

Example:

box2_length = 120 box2_width  = 80 box2_height = 50

📍 STEP 5 — POSITION BOXES (MANUAL MODE)

If auto layout is OFF:

auto_layout = 0

You must manually position each box:

Position system:

• box_x = left/right placement
• box_y = front/back placement

Example:

box2_x = 90 box2_y = 0

💡 Placement tip:
Think of it like a grid inside your drawer.

🧠 STEP 6 — OPTIONAL AUTO LAYOUT MODE

If you don’t want to manually position everything:

Turn on:

auto_layout = 1

Then set:

cols = number of columns

What this does:

• Automatically arranges boxes in a grid
• Spreads them evenly using spacing
• Prevents overlapping (if sized correctly)

⚠️ Important:
Auto layout ONLY controls position, not size.

🧱 STEP 7 — UNDERSTAND PRINT STRUCTURE

Each box is:

• A fully separate 3D object
• Printed individually but generated in one file
• Not physically connected to other boxes

This allows:

• Easy printing
• Easy rearranging
• Custom layouts per user

🖨️ STEP 8 — RECOMMENDED PRINT SETTINGS

For best results:

Layer settings:

• Layer height: 0.2mm
• Wall count: 2–3 perimeters
• Infill: 10–15%

Material:

• PLA (easy printing)
• PETG (stronger option)

Supports:

• ❌ Not required

⚠️ STEP 9 — IMPORTANT RULES

To avoid issues:

• Do NOT overlap boxes in manual mode
• Keep wall thickness ≥ 1.2mm
• Leave small gaps between boxes (1–3mm recommended)
• Ensure box sizes fit inside drawer dimensions
• Always preview before exporting STL

💡 STEP 10 — PRACTICAL USE IDEAS

This system can be used for:

• Desk organization
• Tool storage
• Screw and hardware sorting
• Hobby parts storage
• Kitchen drawer organization
• Electronics components

🚀 WHY THIS MODEL IS DIFFERENT

Unlike fixed organizers, this model gives you:

✔ Full customization
✔ Adjustable layout per drawer
✔ Multiple box sizes in one system
✔ No wasted space
✔ Print everything in one go

🔥 FINAL TIP

Start simple:

• Enable 2–3 boxes first
• Get layout right
• Then expand to full 10-box setup

💬 SUPPORT / UPGRADES

If you want improvements like:

• Internal dividers per box
• Rounded edges
• Snap-fit connections
• Fully automatic packing system

Let me know and it can be upgraded further.

Yeah description is made by ai i aint doing all that ✌️

if there is any problems comment and ill check it out.
