📡 GLYPH: Tactical Off-Grid OS

IT' HEREEE!!

CLICK HERE: PATREON MQR1O_

100% Plug & Play • Zero Soldering • Military-Grade Security

GLYPH is a tactical operating system for the ESP32-S3, engineered for extreme operations where cellular networks fail. It is a professional hybrid between an encrypted walkie-talkie and a GPS breadcrumb tracker, optimized for ultra-low power consumption.

The Revolution? You can build this yourself in under 30 minutes. No soldering iron, no technical expertise required. Just plug the Qwiic modules together and snap the case shut.

🎯 Core Capabilities

• 🔒 Encrypted Messenger (AES-256): Secure private communication via LoRa (10km+ range), using team-based key derivation.
• 📍 Breadcrumb Navigation: Smart offline GPS tracking with KML export to SD card. Filters GPS drift to record only true movement.
• 👥 Team Radar: Track the live position and distance of up to 5 teammates simultaneously on the E-Ink display.
• 🔋 Intelligent Power Management (32h → 70 Days): Features TACTICAL, ECO, STEALTH, and Deep Sleep modes (wakes up on movement via IMU).
• 📱 Companion App: Full control via Bluetooth for seamless messaging, settings, and live telemetry.

🧰 Hardware & Assembly (BOM)

The system uses standard Qwiic modules for instant assembly:

• Brain: LilyGO T3S3 (ESP32-S3 + LoRa + E-Ink integrated).
• Sensors: SAM-M8Q GNSS (GPS), 9-axis IMU (LSM6DSOX), SHT40 Temp/Hum.
• Interface: Arduino Modulino Buttons.
• Enclosure: Optimized for Bambu Lab printers (PETG-CF body + TPU buttons).

🆘 Emergency Shortcuts

• [ A + B ]: Start/Stop Route Recording (Breadcrumbs).
• [ B + C ]: SOS Broadcast (Sends your GPS coordinates to all nearby units).
• [ A + C ]: Shutdown (Enters 70-day Deep Sleep mode).

💻 Software & Pro Access

• Diagnostic OS (Free/Public): Instantly verify your hardware integrity and satellite lock using our browser-based Web Flasher.
• GitHub Repository: Mqr1ooo/GLYPH
• GLYPH PRO: For advanced offline mapping, KML overlays, and the full encrypted messaging suite, support the project on [PATREON MQR1O_].
