3D Printed Flange Alignment Tool

A simple 3D printed flange alignment tool designed to help fabricators line up flanges during pipework fabrication and tack-up.

This tool sits across the flange/pipe section and helps hold a small level in position, making it easier to square up and align flanges before welding. It’s handy for workshop fabrication, pump pipework, spool pieces, stainless pipework, and general fitting jobs where flange orientation matters.

Designed to make flange setup quicker, neater, and more repeatable without needing extra hands.

Features:

• Helps align flanges during fabrication
• Holds a small torpedo level securely
• Useful for tack-up before welding
• Lightweight and easy to keep in the toolbox
• Good for pipefitters, welders, fabricators, and maintenance fitters
• Simple practical design for workshop use

Recommended print material: PETG, ABS, ASA, or Nylon for better workshop durability.

Note: This is an alignment/setup aid only. It is not designed for lifting, clamping under heavy load, or replacing proper measuring and welding procedures.
