This model is a wall-mounted hook system based on a single mount with interchangeable hook designs. This edition is for kid.
It allows the user to select different hook shapes and colors while keeping the same wall mount.

Technical Specifications

• Recommended layer height: 0.2 mm
• Infill percentage: 15%
• Supports: Required

Printing/Assembly Instructions

1. Print the desired hook and the selected mount version (adhesive or screw-mounted).
2. For the adhesive version, ensure the mounting surface is clean and dry before applying double-sided tape to the back of the mount.
3. Press the mount firmly against the wall to ensure proper adhesion.
4. For the screw-mounted version, align the mount on the wall and secure it using two screws through the 4.5 mm diameter holes with a 9.5 mm countersink spacing.
5. Attach the selected hook to the mount.

Additional Components

• Double-sided adhesive tape (for the no-screw version)
• 2 screws compatible with 4.5 mm holes (for the screw-mounted version)
