Changelog :
12.03.2026  --> Update to V5


Additional Material you will need:
1x LED [FCOB 480LED, RA90, 4000K 12V DC] (~2,5m is needed)
1x Power Supply [DC12V ~3A]
1x Set of Magnets (d10x3) (Maybe not needed in your case if you use a tight surround for your Dartboard)
1x Super Glue

Mounting Instruction
0) Print:
   Choose the Printprofile you want to go for
     -) 9th of a full circle LED Segments (also compatible with the Autodarts Attachements)
     -) 10th of a full circle LED Segments

1) Superglue each Joint of the LED Ring (with a “LED-Ring Holder” or “LED-Ring Connector”) as shown in the pictures.

    There is a Mark which symbols the Center of the Holder or the LED-Ring Connector
1.1) 3 LED-Ring Holders need to be placed in the middle of an LED-Ring Segment before glueing the Ring together
       Make sure all of them have the same distance between.
2) Continue this process till you have a closed circle
3) Glue everything firmly together so it will become a strong solid structure
4) Glue the LED Strip into the Ring (The Closer you stick it on the corner “Top Part” the better is the light situation)
5) Turn the Ring upside down
6) Now screw the Camera Modules into the Camera Holder
7) Screw the Camera Holder onto the LED Ring
8) Slide the whole structure onto your dartboard now (It is very helpful if somebody can assist you with that
9) If Needed use some magnets, and use some cable ties to do the Cable management
10) Ready to go
