This project is a DIY modular hydroponic tower, fully 3D printable, designed for vertical growing in small spaces such as balconies, gardens, greenhouses, or indoor environments.

The system allows plants to grow vertically while a nutrient solution flows from the top of the tower down through each module, efficiently feeding all plants with minimal water consumption.

⸻

System Overview

Required Components
• 3D printed parts: Vertical tower modules, plant holders, top cap, base or reservoir adapter
• Water pump: Submersible pump to circulate the nutrient solution from the reservoir to the top of the tower
• Water reservoir: A standard plastic container (recommended 40–60 liters)
• Tubing and connectors: To route water from the pump to the top of the tower
• Optional electronics: Arduino or timers can be added for automation (not required)

⸻

Assembly Instructions
• 3D printing: Print all tower modules using PLA or another suitable filament. Ensure correct STL orientation for watertight connections
• Module assembly: Stack and connect the printed modules to form the vertical tower structure
• Plant holders: Insert net cups or printed plant supports into each module
• Pump installation: Place the submersible pump in the reservoir and connect it to the top inlet of the tower
• Water circulation: The nutrient solution flows downward by gravity, feeding each plant evenly

⸻

3D Printing Recommendations
• Material: PLA (or PETG for outdoor use)
• Infill: 15%
• Walls: 3 perimeters for strength and durability
• Precision: Accurate printing is essential to ensure proper sealing between modules

⸻

Growing Setup
• Growing media: Rock wool, clay pebbles, or coconut fiber
• Supported systems: Ideal for drip-fed vertical hydroponics
• Plant types: Lettuce, herbs, strawberries, leafy greens, and small vegetables

⸻

Maintenance
• Regularly check pH and nutrient levels
• Clean the tower periodically to prevent algae buildup
• Ensure continuous or timed water circulation depending on plant needs

⸻

This 3D printed hydroponic tower is modular, scalable, and customizable, making it perfect for urban farming, sustainable gardening, and personal food production.

3D printing settings

• Material: PLA (or PETG for outdoor use)
• Infill: 15%
• Walls: 3 perimeters for strength and durability
• Precision: Accurate printing is essential to ensure proper sealing between modules
