Transform your H2D from a printer into a powerhouse without needing a screwdriver!

Description

Welcome to the future of printer organization. The Cage isn't just a side panel; it's a structural evolution for your Bambu Lab H2D. This sleek, low-profile Multiboard system turns the unused left side of your machine into a vertical command center.

The secret sauce? Zero-effort integration. The main horizontal bracket is custom-engineered to utilize the existing top spool holder on the back of the H2D. No unscrewing factory parts—it simply hitches a ride on your machine’s native geometry for a rock-solid, hardware-free fit.

Why You’ll Love This Model

• 🛠️ True Plug-and-Play: Uses the back spool holder as an anchor. Zero screws, zero disassembly.
• 💩 Poop Chute Compatible: Choose your flavor! This system includes two notable configurations:
  • The Full Panel: Maximum grid real estate for total organization.
  • The Chute Cutout: Designed specifically to fit perfectly with the H2D Poop Chute by CUBEIFY.
• 🧩 Custom Connector Suite:
  • Base Leg Slots: Dedicated slots to lock the grid to the leg for zero wobble.
  • Plane Spacers: Custom shims to keep your Multiboard perfectly parallel to the printer wall.
  • V2 Bridge: A heavy-duty top connector prepped for the upcoming Top System V2 expansion.
• ⚖️ Sleek & Efficient: Optimized at 2 walls for a fast, filament-sipping print, or 3 walls for a "Heavy Duty" workshop tank.
• 🚀 Future-Proofed: This is just the beginning. The included top connectors are ready for the full enclosure system dropping soon.

Printing Tips (Read Before You Print!)

• Material: PLA is King here. The horizontal bracket is precision-tuned for PLA tolerances. If you use other materials, ensure your Bambu Studio calibration is spot on.
• Orientation: Everything is pre-oriented in the profile for maximum strength and minimal supports.
• Expansion: The profile includes one leg for a standard setup. Need more muscle? Simply duplicate the leg in your slicer to double the support.

Assembly & Hardware

• Hardware Required: NONE. 100% 3D Printed.
• The "Snap" Factor: The horizontal bracket and the legs are two-piece designs. They are engineered with minimal tolerances to ensure a permanent, high-strength bond.
  • Tip: Lay the pieces flat on a sturdy table, align them carefully, and apply firm, even pressure to snap them together.
• Leg Orientation: Ensure the bottom leg clips are pointing toward the grid before snapping.
• Material: PLA
• Installation: Slide the bracket onto the rear spool holder, snap in your leg, and slide your tiles into place.
• Roadmap: The included Top Connector serves as the bridge for the V2 Top System, currently in fine-tuning!
