💻 INSTRUCTIONS, WIRING and FIRMWARE 🪛

 [https://github.com/telepath9/ESPclock](https://github.com/telepath9/ESPclock)

🟠 How to print

• Layer width: 0.4
• Layer height: 0.2
• Perimeters (case): 3
• Supports: no
• Perimeters (lid): 1
• Ironing: on topmost surface

🟡Tip for perfect Light Diffuser (on Orca slicer)

• layer height: 0.2mm
• Filament: PETG or other translucent filaments

1.  select diffuser then right click on it
2.  Click Height range modifier → choose Range: from 0mm to 0.2mm
3.  Enable IRONING: on all solid layers (only applied to the diffuser)
4.  Print. Done.

🛒 PART LIST

• XIAO ESP32 C3 or Wemos D1 MINI (mine is V3.0.0 clone)
• TM1637 module [https://it.aliexpress.com/item/1005001582129952.html?spm=a2g0o.order_list.order_list_main.49.370e3696i4W9Sn&gatewayAdapt=glo2ita](https://it.aliexpress.com/item/1005001582129952.html?spm=a2g0o.order_list.order_list_main.49.370e3696i4W9Sn&gatewayAdapt=glo2ita)
• Dupont wires
• DG308 7pins terminal block (for XIAO) OR DG308 8pins terminal block (for WEMOS): x2
• Female 7pins header(for XIAO) OR Female 8pins header (for WEMOS): x2
• 7x3cm perfboard: x1
• M2.5 screws: x10
• M2.5 nuts: x2
• Single row female 5pins header (for common GND): x1
