This is a robust, fully adjustable, and foldable stand designed to hold everything from heavy books and dictionaries to tablets and music sheets. Its clever mechanical design ensures maximum stability while remaining incredibly easy to print and assemble.

Key Features

• A1 Mini Friendly: Every part is designed to fit within a 180 x 180 mm print bed. No large format printer required!
• Adjustable Tilt: Featuring a multi-position rear support with a screw-locking mechanism to find your perfect viewing angle.
• Extendable Stabilizers: Built-in telescopic feet that slide out to provide extra leverage, ensuring the stand won't tip over even with oversized books.
• Foldable Design: Flat-pack capability for easy storage or transport in a backpack.
• Professional Build: Designed for long-term use using a mix of 3D printed parts and standard hardware.

Hardware Required

To complete the assembly and ensure maximum mechanical durability, you will need:

6x Rivets (4mm diameter): These are used for the main hinges and pivot points. Using rivets instead of screws provides a permanent, smooth rotation and prevents the joints from loosening over time.

you can also use an M8 screw at least 75mm long, 22 of which are threaded, and a suitable nut instead of the screw inserted into the print for greater resistance.

Print Settings Printer:

Optimized for Bambu Lab A1 Mini (or larger).

Filament: PLA, PETG (PLA is recommended for maximum structural rigidity).

Infill: 15-20% (Gyroid is recommended).

Wall Rings: 5 or 6 for added strength around the rivet holes.

Supports: Minimal (tree supports are recommended for overhangs).

Assembly Instructions Preparation: After printing, ensure the 4mm holes are clean. You can gently drill them with a 4mm drill bit for a perfect fit.

Riveting: Align the main panels and the rear support arm. Insert the 6 rivets into the hinge points and secure them.

Adjustable Arm: Install the rear adjustment screw to control the tilt.

Finishing Touches: Slide the extendable feet into the base. Felt pads or rubber feet can be added to the recessed circular areas on the back to provide a firmer grip on the table.
