Summary: A heavy-duty hanger designed to fit standard office cubicle walls. This model features a long, angled hook perfect for holding heavy backpacks, winter coats, or headphones without them slipping off.

Design Features:

• Secure Fit: Designed with a deep top channel to sit securely over partition walls.
• High Capacity: Features a 132mm long angled arm (34° angle), providing ample space for thick straps or multiple items.
• Stable Profile: At 26mm wide, the hook distributes weight effectively and resists twisting.

Print Settings:

• Material: PLA is recommended and works great for standard office loads.
• Variable Layer Height:
  • Adaptive: 0.60
  • Smooth Radius: 6 (Click 2 times)
• Layer Height: 0.16 mm
• Initial Layer Height: 0.16 mm
• Orientation: Print on its side (as shown in the model photos) for maximum strength and layer adhesion.
• Supports: No supports required when printed on its side.

Dimensions:

• Overall Width: ~26mm
• Hanger Arm Length: ~132mm
• Top Bracket Depth: ~71mm (Outer dimension)
