STACKED Modular Wall Planter - Wall Mount Kit (Top, Bottom, and Spacer)

Print Settings (Description and Parts List Below)

Wall Loops: 6

Sparse Infill Density: 40%

Sparse Infill Pattern: Cubic

Ironing: Enabled - Rectilinear

Filament Type: PLA, PLA+, PETG

The STACKED Modular Wall Planter is a project I've spent a while designing and, after 2 weeks of using it, I can say it has been well worth the effort. This wall planter has a modular design, allowing you to customise it exactly how you want.

Please keep in mind that this particular file is ONLY the mounting kit to attach the dowel rod to the wall, none of the attachments are included in this file, however they are available on my profile, and I will be adding more soon :)

This design was made to be compatible with 25.4mm (1in) Wooden Dowel Rods, and I recommend using a length of between 100cm and 180cm, any more may be too heavy, however I am working on a reinforced version of these mounts, to be released soon.

You Will Need:

• 1x 25.4mm (1in) Diameter Dowel Rod, Between 100cm and 180cm Long
• 2x 4mm x 50mm Non-Countersunk Screw with a head diameter on 10mm or less.
• 2x Green Wall Plugs
• 80-100g of PLA, PLA+ or PETG

Where To Find The Dowel:
Australia: [https://www.bunnings.com.au/porta-25-4-x-25-4mm-1-2m-tasmanian-oak-dowel_p0099506](https://www.bunnings.com.au/porta-25-4-x-25-4mm-1-2m-tasmanian-oak-dowel_p0099506)

New Zealand: [https://www.bunnings.co.nz/25mm-pinetrim-dowel_p0293785](https://www.bunnings.co.nz/25mm-pinetrim-dowel_p0293785) (Wrap 2 layers of electrical tape around each end to make it fit)

United States: [https://www.homedepot.com/p/Pine-Round-Dowel-48-in-x-1-in-Sanded-and-Ready-for-Finishing-Versatile-Wooden-Rod-for-DIY-Home-Projects-6216U/329566304](https://www.homedepot.com/p/Pine-Round-Dowel-48-in-x-1-in-Sanded-and-Ready-for-Finishing-Versatile-Wooden-Rod-for-DIY-Home-Projects-6216U/329566304)


Enjoy!
