Adjustable Phone Mount for CB Stellaris Controller

This is a custom-designed, adjustable phone mount made specifically for the Cosmic Byte Stellaris controller. Since no compatible mount was available in the market, this model was designed from scratch to securely hold any smartphone size using an adjustable screw mechanism.

The mount clamps the phone firmly while maintaining balance and a comfortable viewing angle for long gaming sessions.

✅ KEY FEATURES

Designed specifically for Cosmic Byte Stellaris controller
Adjustable phone width using central screw clamp
Adjustable viewing angle using side angle screws
Side screws allow fine-tuning tilt for comfortable long gaming sessions
Universal compatibility with most smartphones
Secure grip with balanced weight distribution
No permanent modification to the controller
Lightweight yet sturdy design

✅ IMPORTANT ASSEMBLY & USAGE NOTES (READ CAREFULLY)

The side adjustment screws control the viewing angle
Small side screws are marked “R” (Right) and “L” (Left)
Install R and L screws only in their respective sides
- Threads are designed direction-specific
- Incorrect placement may damage threads or affect adjustment
Tighten screws gently to avoid overtightening
Adjust angle first, then lock position with light pressure

✅ PRINT & HARDWARE RECOMMENDATIONS

Printer Type: FDM
Material: PLA / PLA+ (PETG recommended for durability)
Layer Height: 0.2 mm
Infill: 15–30%

Hardware

Central clamp screw (as designed)
Two small side angle screws (R & L specific)

Note: Please follow assembly instructions carefully. Incorrect screw placement may affect adjustability.
