Flight Data Recorder (FDR) – Custom Educational Model

This is a custom-designed Flight Data Recorder (Black Box) model, created for educational, display, and aviation-related projects.

The model is designed to be:

• Modular and easy to print
• Suitable for students and aviation enthusiasts
• Ideal as a desk display, teaching aid, or project prop

Features

• Multi-part design for easier printing and assembly
• Clean geometry optimized for FDM printers
• Can be printed in single or multi-color
• Scalable to different sizes
• Cut / separated print files included for easier printing

Assembly

• Some small parts require glue (e.g., super glue or B7000) for bonding
• Light sanding may help for better fit and finish

Recommended Print Settings

• Layer height: 0.2 mm
• Infill: 15–20%
• Supports: Only if needed (depending on orientation)
• Material: PLA or PETG

Notes

• This is a non-functional, conceptual model intended for educational and display purposes only.
• Feel free to remix or scale for your own projects.

Designed by 3Dreamed
If you use or remix this model, I’d love to see your makes!

This model was created as part of a student aviation project and personal 3D printing practice.
