Modelo 3D General Purpose Junction Boxes por IF PRJ 🌱 no MakerWorld

Descrição

This is a general purpose junction boxes project with low profile to be used for indoor, outdoor or inside walls cable routing and connections.



Option A: 6 x 16-25mm conduit inlets/outlets | Chamfered edges for better sealant adhesive placement (plate #1)

Option B: 6 x PG11 cable glands (plate #2)



Optional flange for lid is on plate 3 for TPU print.



Wall mounting bottom thread for M5/M6/M8mm screws / 4 x M4 threaded screws of up to 18mm long can be used for the lid.

MakerWorld

General Purpose Junction Boxes

Publicado em 11 de dez de 2025

125
Curtidas
129
Downloads
323
Coleções
51
Impressões
Categoria Other Tools
Tags
junction box M4 flange pg11 16-25mm electric connections electric cables cable routing
Licença Standard Digital File License
