This model was completely custom-built and did not reference the dimensions of other projects.

[https://makerworld.com/en/models/2031310-snapmaker-u1-top-cover-modding-for-ikea-samla-45l?from=search#profileId-2191227](https://makerworld.com/en/models/2031310-snapmaker-u1-top-cover-modding-for-ikea-samla-45l?from=search#profileId-2191227)

Update: Profile Added (Feb 18)

[NEW Version] This version was created following requests for a top screw-mount option.

1. Compatibility: It is compatible with the existing top printed parts. You can reuse the center pieces and only need to print the 4 new parts for the front and rear.
2. Caution: The screw-mount sections are delicate. Please tighten the screws by only 1 or 2 turns to prevent damage.
3. Tip: Using the original rubber caps will give it a more polished and finished look.

This model was inspired by a user's work.

This project also used the IKEA SAMLA 57x39x28cm/45L.

1. Mounting was done using the top holes instead of attaching to the frame.

2. Print time was reduced to approximately 10 hours.

3. It was split to fit a P1 or A1 sized bed.

4. Infill was added to the hole mounting areas using a modifier.

5. Eight pins were inserted into the frame to secure the IKEA box.

6. Both print profiles are sealed.

7. During PLA printing, the chamber temperature is maintained at approximately 40°C.

There are two models:

Model requiring cable separation: Closed back
Model without cable separation: Open back

Print the desired model.
