HDMI StashBox – Parametric is a fully customizable back-mount storage box that attaches to any standard HDMI port. Designed to hide your stash behind a monitor, TV or any device with an HDMI port, this model is perfect for organizing tight spaces where you normally can’t mount anything.


The design is fully parametric, allowing you to adjust dimensions, tolerance, wall thickness, and internal space to fit your specific needs. Whether you want a slim-profile box or a deeper container, the included parameters make it easy to modify.

Simply plug the integrated HDMI dummy connector into an unused HDMI port, and you instantly gain hidden storage behind any screen.

🛠️ How to use

• Download HDMI StashBox - Parametric - Fusion 360.f3d
• Edit parameters in Fusion 360

⭐ Feature List

• ✓ Fully Parametric
  Adjust width, height, depth, wall thickness, tolerance, and more.
• ✓ Integrated HDMI Dummy Connector
  Slots securely into any HDMI port without interfering with electronics.
• ✓ Hidden Storage Behind Monitors/TVs
  Hide anything somewhere no one will think to look
• ✓ Modular & Customizable
  Change the storage volume, connector thickness and tolerance.
• ✓ Secure Fit
  Optional tolerance settings ensure tight or loose fit depending on your printer.
• ✓ Strong Hingeless Design

🖨️ Print Settings

These settings were tested on a Bambu P2S

Layer Height: 0.2 mm
Wall Count: 2 walls
Infill: 15 percent (higher if you want a stronger connector)
Material: PLA, PETG (PLA is fine for most uses)

Supports:

• Lid: No supports
• Box if printed at an angle : Tree (manual) . (paint in a minimum of support on the bottom and back of the box)

Print Orientation:

• Box: Recommended to print at a 45 degree angle to have a clean and strong HDMI connector
• Lid: Print with open side facing upwards
