🖼️ Wall-Mounted TCG Card Frame – Modular, Customizable & AMS-Friendly

This wall-mounted display frame is designed to be intentionally generic, making it easy to modify, customize, or remix.
If you want to adapt it with ornaments, logos, text, themed trims, or color accents, the flat surfaces allow for simple external additions.

The system consists of three printed pieces:

1. Top Clip – holds the card in place from above.
2. Bottom Base – supports the card and keeps it aligned.
3. Wall Mount Bracket – attaches to the wall using strong double-sided tape.

The frame slides onto the wall mount bracket using a small integrated support tab.
This tab is minimal on purpose—just enough to hold the clip mechanism while keeping the model lightweight and easy to assemble.

✨ Features

• Intentionally generic design: ideal for mods, add-ons, color accents, or themed variations.
• AMS-friendly:
  If you use a multi-color AMS, I recommend printing decorative or colored detail pieces separately and gluing them onto the frame.
  This saves purge material and gives cleaner results.
• Modular 3-piece system for easy maintenance and card swapping.
• No screws or nails: wall mount is designed for double-sided tape.
• Lightweight and safe for walls and furniture surfaces.
• Quick printing: optimized to be printed without supports.

🛑 Card Safety

Before inserting your card, check the top clip groove for minor printing burrs.
A smooth groove prevents pressure marks on the card edges.

Need a looser fit for sleeves, thicker cards, or top loaders?
Just ask and I can generate adjusted versions.

📐 Included Sizes

• Standard TCG (Pokémon, MTG, One Piece, Dragon Ball, etc.)
• Additional sizes available on request.

🖨️ Print Recommendations

• Material: PLA
• Layer height: 0.16–0.20 mm
• Perimeters: 2
• Infill: 15%
• Supports: Minimal
• Adhesion: Brim optional

💬 Customization

This model is ideal for:

• Color trims or overlays
• Nameplates or emblems
• Side decorations
• Themed frame variants
• Parameter adjustments

If you want a modified version, leave a comment and I’ll be glad to help.
