This is an SCX24-based Comp Frame:

This frame is for an SCX24, and it is made to be a competition(Class-3, I think) Chassis. I have built it around a brushless outrunner system, and it is a tight fit. I have to run my receiver naked (Which is not a problem), but it does limit the amount of features you can fit inside. I am running the battery on the axle for a lower center of gravity and more space inside.

THIS IS A WORK IN PROGRESS

Electronics/Hardware:

 I am running an RCEnjoy Brushless ESC, 2204 Motor, and Transmission (Amazon)

Injora INJS480 Micro servo on a Meus Emax mount (You will need a sevo lead extension)

VICMLE 450 Mah Battery (  Any SCX24 Footprint battery should work)

SLR300 Receiver (Has to be run with no case)

RampCrab Suspension Links (I run Gladiator wheelbase, but any wheelbase will work)

Generic Brass Skidplate

Meus Drive shafts ( same wheelbase as links)

SCX24 Axles (any should be fine)

Mostly Injora Hardware( The occasional OG scx24 hardware)

3d Printed Beadlock rims

Injora 1.0  65mm comp pin tires ( please run 65mm tires, they just work better on this rig)

Injora Brass Extended axle hexes ( I shaved a little off the end to get the width I wanted)
