Clock Position Finder for Pipeline Integrity (NDT Tool)

Description:
This 3D-printed tool is designed to simplify and standardize clock position referencing during pipeline integrity inspections.

It provides a clear and repeatable way to identify and communicate defect orientation (@ 2:15”) directly on cylindrical pipe surfaces. The integrated bubble level ensures consistent horizontal alignment, while the rotational clock face allows precise visual indication of position around the pipe’s circumference. (Markings are down to 0:15 minute increments.)

Features:

• Built-in bubble level
• 12-hour clock dial with 15 minute increments
• Center guide for marker
• Fits snugly against curved pipe surfaces using the inset magnets (6 - 20x3mm)
• 3D printable without supports on most FDM printers

Use Case:

• Pipeline NDT inspections (UT, PAUT, RT, EC, etc.)
• Automated Corrosion mapping - Marking Top Dead Center or position of scan starting locations.
• ILI Data correlation with physical defect locations
• Technician training and visual reference in reporting photos

Simply align the tool’s level bubble, note your clock position, and mark or record your data point confidently. Perfect for ensuring consistent orientation documentation across crews and inspection methods.

Pause Printer at layer 226.

Insert 3 - 20x3mm round magnets into each slot

Continue Print

Use a 8mm 2.5mm button bold with washer and hex nut.

Bubble Level will Slide into the insert on the Dial and fit snuggly in place. You can add some CA glue if needed.
