Need a simple way to mount a tablet to the wall, without sacrificing charging access?  This beveled wall mount holds a 240×163 x7mm tablet securely at a slight angle, keeping the screen easy to see and touch.

It prints in four pieces that slide together easily:

• Tablet Support – cradles the device with an open bottom for cable access
• Tablet Top – securely holds the tablet in place
• Angled Brace – holds the tablet away from the wall at a convenient angle
• Wall Mount Plate – can be printed flat for screw mounting or upright for use with an XL Command Strip

No supports required, but a wide brim will help prevent the tablet pieces from failing.

Assembly is straightforward:

1. Slide the Tablet Support onto the Angled Brace
2. Insert the tablet
3. Slide on the Tablet Top
4. Mount the Wall Mount Plate with a command strip or 2 screws at 2.25" on center
5. Slide the whole assembly into place on the Wall Mount Plate

Note: This version is not parametric, but a customizable version may be released in the future.
