Modular Shelf for HomeRacker

Infinitely Scalable

Modular Shelf

for

HomeRacker

👀 Looking for the Gridfinity Shelf ❓

It has been moved to a separate model.

Find it here

Adhesion Problems?✂️

When using the “Customize” functionality above, make sure to “Split to Objects” in the Bambu Slicer and "Arrange"!
This is important to make the Slicer aware that there might be more than a single body in the model. → Gives the shelf supports a brim for better bed adhesion.

This model is an extension of the HomeRacker - Core system.

🌐 All-Purpose Shelf consisting of 2 components
- Shelves that can be inserted into a HomeRacker Core frame
- Shelf Supports that hold the shelves along the depth axis

Features

📈 Scalable in ANY direction

Not just in width and height, but also in depth. If you need a deeper shelf, you can simply attach one to the front or back. The shelves are designed to not overlap on a support, making extension almost seamless. Scale to your needs by clicking on the green “Customize” button above.

🔀 Mix and match

Like any other HomeRacker extension, these shelves are fully compatible with everything in the HomeRacker ecosystem.

In the picture below, you can see the so-called “Abomination”—part 10" rack, part 19" rack, part bookshelf. This one’s straight out of the nuclear wasteland known as my HomeLab... and may never be released in this exact form 😄

🔧 Fully parametric

I’ve included fully parametric .f3d files (Fusion 360) so you can tweak and customize it to your heart’s content in the Parametric model maker or locally.

What is HomeRacker?

HomeRacker is a universal modular rack building system I created. It's based on an open specification. Find out more here:

HomeRacker - Core on Makerworld

or visit

[https://homeracker.org/](https://homeracker.org/)

or checkout

The Official HomeRacker Collection

With HomeRacker, you can build all sorts of things—like the Dry Filament Shelf or this 10" Cyberpunk-style rack which you can also find on Makerworld. Check it out!

What's in the Box??

The included print profiles contain only the exact models shown in the print profile pictures, plus a bunch of lock pins.

These are somewhat complex builds, designed to demonstrate the system’s versatility.

If you want to create a custom build with different-sized shelves, I’ve added the original f3d-files alongside the print profile:

The original hex-style all-purpose shelf called HomeRacker - Shelf v21.
Just adapt the parameters shelf_width_units and shelf_depth_units to fit your design.

Let me emphasize one thing:

The attached print profiles are only examples!

Their only purpose is to give you a SMALL glimpse of what's possible.

I designed HomeRacker in a way, that you can build basically ANY shelf combination you fancy.

So: Be creative :-)

What's missing?

The rack frame itself is not included in this model (only selected parts).
To build a complete setup or get additional connectors and supports, download the free HomeRacker - Core system.

Which size to choose?

If you want to customize your own all-purpose shelf, here’s what to keep in mind:

tl;dr: Support Lengths = Frame Dimensions

Max Dimensions (for hex shelves)

Depending on your printer, you'll have limitations on the maximum shelf size you can print. Here's a comparison across three printers:

A1 Mini: 12x11
P1S/X1C: 16x16 (if you tweak printer settings to ignore the exclusion area even more)
H2D: 21x20 (just played around in Bambu Studio — no actual clue if you can use two nozzles to print the full range)

🏗️ The thickness of the shelf will increase by 0.1mm per depth unit to ensure stability when customizing bigger shelves.

Community Driven

Many of you have already shared great ideas with me — thank you! Unfortunately, my time is very limited. That's why I created the open specification (see Technical Specs), so anyone can create extensions and models for HomeRacker without license restrictions. If you have an idea and the ability to design CAD models, please go ahead — I'd be happy to link your creations in the catalog!
If you're not familiar with CAD design, feel free to pitch your idea to me with as much detail as possible.

Check out the glorious
Community Catalog

Pitch ideas or vote for them
here on GitHub!

Join the

KellerLab Discord Server

Support

If you appreciate this model and wanna buy me coffee, you can do so here: [https://ko-fi.com/kellervater](https://ko-fi.com/kellervater)
Or simply scan this QR-Code:

Changelog

[13.10.2025]

✅ Extracted the Gridfinity Shelf into a separate model

[23.09.2025]

🐛 Gridfinity Shelf: Fixed ledgers blocking connector lock pin holes.

[14.09.2025]

➕ Added a new print profile for a Showcase - Gridfinity Shelf and a corresponding manual

[13.09.2025]

💪 added y-axis supports to better distribute weight. There's always 2 of them per side and an alternative double-sided support. This feature is now part of the customizable Gridfinity Shelf v35
🗑️ removed deprecated folders/files in favor of customizable models. Did it because changes to this model (even a few lines of text) took forever to verify.

[12.09.2025]

✨ Added customizable Gridfinity Shelf. Just select “Gridfinity Shelf v32” when clicking on Customize.
🎨 All-purpose shelf is now customizable. Just select “HomeRacker - Shelf v21” when clicking on Customize.
👴 Since there's the customizable version now, folders with specific dimension files are now DEPRECATED. The files will be removed by the end of the year in favor of the parametric files.
🏗️ The all-purpose shelves strength has been improved. The shelf thickness scales now with the `shelf_depth_units` by a factor of 0.1mm per unit.

[01.05.2025]

Uploaded A1-Mini Showcase print profile

[23.04.2025]

First upload of mk.1

[28.04.2025]

Uploaded a ton more dimensions. The range now goes fro 4x3 up to 17x23 and all in between. That's 294 different shelf sizes. No worries. I created a small python script which does these exports for me. However, next time I'll create an openscade file. Problem is, that I reached the max upload limit of 500MB already.
