Stackfinity - A Gridfinity Modular Storage System — STL Grátis

Be sure to check all sizes - “Click to see more” in Profile list

Introducing Stackfinity, a new desk organizer storage solution for all of your fasteners that integrates Gridfinity and is stackable. Drawers are held in place and easily slide in/out, now with the ability to lock in place halfway out. Print the optional labels and either write on them with a marker or use the text tool in your slicer.

Looking for Parametric Labels? Check out this generator by BlainLeVilain!

Bambu Studio Zombie Tuned print profiles are now available!

Print Settings:

Layer Height: 0.2mm
Supports on drawers only: Recommended (Supports on front lip ONLY)
Zombie Tuned print profile: Recommended
Polymaker Panchroma PLA: Strongly recommended (affiliate)
Bed Adhesive: Vision Minor Nano Polymer (Code HEDGEHOG at checkout)

File naming convention:

6S - Slot units wide
[2x5] - Two Gridfinity units deep, Five Gridfinity units wide
[2x] 9S- Two Gridfinity units deep, 9 slots wide
Small - Drawer height

Instructions:

Congratulations on your new Wacky Stacky unit! In order to stack, the main Gridfinity unit base size must match for each stack, for example [2x3] stacked on a [2x3], or a [3x6] stacked on a [3x6].
Once you pick the width of your main unit, print out as many bins as you want that will fit. A 6 slot unit will fit one 6 slot bin, or two 3 slot bins, or one 2 slot and one 4 slot bin, etc etc etc.
Units of different heights can be stacked as shown in the example pictures, as long as the gridfinity base size is the same. A [2x4] Small unit will snap onto a [2x4] Medium unit and vice versa.

Missing the size you need? Feel free to direct message me with your requests or contact me on Discord! [https://discord.gg/Fa8zUsjfgV](https://discord.gg/Fa8zUsjfgV)
