AMS Lite 2.0

NEW VERSION

About AMS Lite 2.0

AMS Lite 2.0 was developed to improve compatibility, ease of use and the overall user experience compared to the original AMS Lite.

Thanks to a redesign of the spool support system and the positioning of the motor units, AMS Lite 2.0 addresses some of the main limitations of the original design while maintaining full compatibility with the Bambu Lab ecosystem.

Spool Compatibility

AMS Lite 2.0 has been designed to support a wide range of 1 kg spools available on the market.

The system is compatible with both plastic and cardboard spools, including many brands that are difficult or impossible to use with the original AMS Lite.

Unlike the original system, which relies on the spool's internal diameter, AMS Lite 2.0 uses a roller support system that eliminates dependence on the spool core diameter. This allows most spools to be used without dedicated adapters, significantly improving compatibility with third-party filament manufacturers.

Reuse of Original Hardware

One of the main goals of AMS Lite 2.0 was to minimize the need for additional hardware purchases.

With the exception of the ball bearings required for the roller system, all electronic components, motors, screws and hardware are reused directly from the original AMS Lite.

AMS Lite 2.1 Enclosure

For users interested in protecting their spools from humidity, a dedicated project called AMS Lite 2.1 Enclosure is available.

This upgrade requires reprinting only a limited number of components, mainly the motor supports and the electronics compartment, allowing AMS Lite 2.0 to be installed inside an IKEA enclosure.

🔗 AMS Lite 2.1 Enclosure

RFID Support

AMS Lite 2.0 maintains compatibility with the original Bambu Lab RFID system.

Users can choose between two versions of the project:

No RFID version
RFID-compatible version

For the RFID-compatible version, two possible solutions are available.

RFID Cable Extensions

It is possible to create extension cables using the connectors linked in this description, avoiding permanent modifications to the original wiring.

However, this solution has not been directly tested and therefore I cannot guarantee its effectiveness.

🔗 male connector (Optional product)

🔗 female connector (Optional product)

Direct RFID Cable Modification

The original cables can be cut and extended to fit the new configuration.

This solution has been tested and is fully functional, but it involves an irreversible modification that voids the product warranty.

Technical Recommendations:

Use cables with a cross-section of 0.75 mm² for better signal transmission.
Twist the wires together to reduce electromagnetic interference.
Measure cable length after twisting, as twisting reduces the total length.
Always add a 1–2 cm safety margin during installation.

Upper Holder

For users who want to reduce the space occupied on their desk, a dedicated project called AMS Lite 2.0 Upper Holder is also available.

🔗AMS Lite 2.0 Upper Holder

Dimensions

For a visual reference of the system, please refer to the model cover images.

Width : 41 cm
Depth : 31cm

Required Original Components

AMS Lite 2.0 is designed to reuse the original AMS Lite hardware.

If you already own an AMS Lite, there is no need to purchase these components again, as they can be transferred directly to the new system.

If you do not own an AMS Lite, spare part availability and prices in your region, purchasing individual components may be more cost-effective than purchasing a complete AMS Lite.

The required components are:

Due to the variables mentioned above, each maker is encouraged to compare both options and determine which solution is the most cost-effective for their specific situation.

Required harware

To complete the project, you will need to purchase PTFE tubes and ball bearings.

The longer PTFE tubes will be cut from the purchased tubes and will have a length of 106 cm and 100 cm. These tubes will connect motors 3 and 4 to the extruder connectors located at top left and bottom left when looking at the printer from the front.
For motors 1 and 2, the original longer tubes from the printer will be used, which will connect the motors to the extruder connectors at top right and bottom right.

To keep the tubes organized, I recommend downloading and printing the following hooks for optimal management.
🔗 Link to download hooks

RFID System

To maintain automatic recognition of official Bambu Lab spools, AMS Lite 2.0 has been designed to accommodate the original RFID readers.

It is important to note that this procedure requires cutting and extending the original RFID cables. Since this is an irreversible modification, it may void the AMS Lite warranty.

For this reason, each maker can freely decide whether or not to use the RFID system based on their own needs. It should also be considered that RFID is not essential, as A1 and A1 Mini printers allow material selection directly from the touchscreen.

Spool Rewinding

One of the most frequently asked questions concerns automatic spool rewinding.

Unlike the original AMS Lite, AMS Lite 2.0 does not use a dedicated mechanical rewinding system.

With current Bambu Lab firmware versions, the filament is only retracted a few centimeters during filament changes. This retraction creates enough tension to naturally rewind the filament onto the spool, keeping it properly positioned without any risk of tangling or jamming.

Conclusion and Video Tutorial

Now, I leave you with the links to the tutorial and the AMS Lite disassembly guide:

🔗 AMS Lite Disassembly Guide
🔗 Video Tutorial

Good luck and happy printing! 😄
